ViewShare Fusion

Support

Questions about ViewShare Fusion?

Check our FAQs for the answer.

Is ViewShare Microsoft Certified?

The Logitech C930e and Jabra SPEAK components included with ViewShare are both Skype for Business Certified, and optimized for use with Skype and Lync.

Does ViewShare Fusion work with other peer-to-peer software beyond Lync and Skype?

ViewShare’s components are optimized for use with Lync and Skype, and Skype for Business Certified, but should work with any peer-to-peer software that allows the input of external audio/video devices.

Does the ViewShare Fusion camera have pan, tilt and zoom capabilities?

Yes. The Logitech Webcam C930e includes zoom to 4x in 1080p and has an optional light application for control of pan, tilt and zoom.

The application can be downloaded here.

Are there multiple options for positioning the ViewShare Fusion camera?

Yes. ViewShare Fusion has options for placing the camera above, below and between displays. Above/below models include 180˚ of swivel, 0-180˚ of tilt and 3.1-6.3” (79-160 mm) of depth adjust. Center models include 3.2-5.2” (81-132 mm) of depth adjust and no tilt or swivel.

Above/below camera placement: FCA800V, FCA810V, FCA800VE, FCA810VE
Center camera placement: FCA820V, FCA820VE

Is ViewShare compatible with both PC and Mac devices?

Yes, ViewShare is compatible with Windows 7 or 8 and Mac OS X 10.7 or higher.

Do I need to download drivers for the Logitech camera?

It is not necessary to download drivers for the Logitech camera, but is highly recommended to ensure optimum camera performance. The optional light application is required to utilize the pan/tilt capabilities.

The application can be downloaded here.

What are the system requirements for using ViewShare?

Windows 7 or 8
Mac OS X 10.7 or higher
2.4 GHz Dual Core processor or better
2 GB RAM or more
USB 2.0 port (USB 3.0 ready)

ViewShare is using my device’s audio input/output – how do I get it to use the Jabra speakerphone?

Windows – In Lync/Skype click the gear wheel to open the Options window > choose Audio. Select Jabra SPEAK 410 USB from the drop down menu.

OS X – Go to the Lync/Skype menu > Preferences and choose Audio or Audio/Video. Select Jabra SPEAK 410 USB from the drop down menu.

ViewShare is using my device’s internal camera – how do I get it to use the external Logitech camera?

Windows – In Lync/Skype click the gear wheel to open the Options window > choose Video. Select Logitech Webcam C930e from the drop down menu.

OS X – Go to the Lync/Skype menu > Preferences and choose Video or Audio/Video. Select Logitech Webcam C930e from the drop down menu.

Can’t find the answer to your question? Please contact us at our Customer Care team at 1-866-977-3901 or chief@chiefmfg.com

  • Related Products
  • Features
  • Videos

Related Products

Features

  • HD camera accessory can be installed above, below or between displays.
  • Easy USB connectivity
  • The Logitech C930e and Jabra SPEAK components included with ViewShare are both Skype for Business Certified, and optimized for use with Skype and Lync.

Includes:

  • Fusion mount accessory with integrated HD camera
  • 10' (305 cm) USB cable
  • USB speakerphone
  • Powered USB hub
  • USB A/B gender adapter (Only on non-extender versions)
  • Local USB to CAT5 extender with power supply (only on extender versions)

Logitech Webcam:

  • Full HD 1080p video calling (up to 1920 x 1080 pixels) with supported clients
  • Supports H.264 SVC 1080p for Microsoft® Lync™ 2013, along with optimizations for best call performance in single or multiparty HD video
  • 90 degree field of view
  • Rightlight™ 2 Technology for clear image in various lighting environments, even low light
  • Optional light application for control of pan, tilt and zoom
  • Carl Zeiss® lens certification
  • Hi-Speed USB 2.0 certified (USB 3.0 ready)

Jabra SPEAK 410 MS:

  • Connects via USB
  • Microsoft Certified
  • Wideband Hifi Frequency Response
  • Digital Signal Processing (DSP) digitally optimizes voices and suppresses echoes
  • Omni-directional/noise filter eliminates background noise
  • Standard (E-STD) Microphone Sensitivity - Standard (STD) variation microphone sensitivity is comparable to a normal telephone receiver and is used in most telephone devices

System Requirements:

  • Windows 7 or 8
  • Mac OS X 10.7 or higher
  • 2.4 GHz Intel® Core 2 Duo processor
  • 2 GB RAM or more
  • Hard drive space for recorded videos
  • USB 2.0 port (USB 3.0 ready)

Suitable for use in environmental air space in accordance with section 300-22 (c) of the National Electric Code, and sections 2-128, 12-100 of the Canadian Electrical Code, part 1, CSA C22.1.

See full list of specs on the downloads tab.

Videos

ViewShare Fusion Video Conferencing Kits
